Base Sculptures™
Profiled Wall Base System
Sculptured, wood-look rubber base
SUPERIOR FLEXIBILITY TO FIT EVERY STYLE + SPACE
Base Sculptures Profiled Wall Base System delivers a wood-like appearance with enhanced durability. This flexible base is made from durable thermoplastic rubber that conforms better to wall irregularities and is available with coordinated corner blocks for easy installation. The Base Sculptures system comes in multiple colors, profiles, heights and gauges to satisfy any requirement.
Certifications
Outstanding design, selection and performance
- 18 distinct profiles available in 72 colors
- Made with virgin raw materials
- Phthalate-free, plant-based plasticizers reduce greenhouse gases by up to 10%
- Resilient base wears well without chipping
- Fits snugly against uneven walls
- Harmony, Merit, Charisma and Reflection profiles available in 40' coils for seamless installation
Specifications
| Gauge | 1/8" to 1/2" nominal | |
| Wall Heights | 2-5/8", 3", 4", 4-1/4", 4-1/2", 4-5/8", 5", 5-1/4", 6" and 7-3/4" | |
| Lengths | 40' rolls 8' lengths |
|
| Corners/Ctn. | 15 | |
| Lbs./Ctn. | Lin. Ft./Ctn. | |
| Harmony | 25 Lbs. | 40' roll |
| Merit | 16 Lbs. | 40' roll |
| Charisma | 40 Lbs. | 40' roll |
| Reflection | 46 Lbs. | 40' roll |
| Regal | 32 Lbs. | 8' Pcs., 5 Pcs./Ctn. |
| Charmed | 55 Lbs. | 8' Pcs., 16 Pcs./Ctn. |
| Echo | 44 Lbs. | 8' Pcs., 5 Pcs./Ctn. |
| Icon | 52 Lbs. | 8' Pcs., 6 Pcs./Ctn. |
| Captivate | 55 Lbs. | 8' Pcs., 9 Pcs./Ctn. |
| Bliss | 48 Lbs. | 8' Pcs., 5 Pcs./Ctn. |
| Whimsical | 54 Lbs. | 8' Pcs., 6 Pcs./Ctn. |
| Triumph | 49 Lbs. | 8' Pcs., 5 Pcs./Ctn. |
| Enchanted | 50 Lbs. | 8' Pcs., 6 Pcs./Ctn. |
| Noble | 50 Lbs. | 8' Pcs., 10 Pcs./Ctn. |
| Marquis | 50 Lbs. | 8' Pcs., 4 Pcs./Ctn. |
| Escalate | 51 Lbs. | 8' Pcs., 5 Pcs./Ctn. |
| Resolute | 47 Lbs. | 8' Pcs., 4 Pcs./Ctn. |
| Fascinate | 53 Lbs. | 8' Pcs., 4 Pcs./Ctn. |
product brochure
Information sheet
AVAILABLE PROFILES
Available colors
Blush 500
Cappuccino 065
Meditation 514
Winter Gray 529
Black Brown 071
Bullseye 503
Bondi Blue 521
Lilac 532
Gray 036
Cinereous 501
Almond 022
Cinder 515
Windswept 530
Camouflage 505
Toucan 504
Rackley 522
Rose Quartz 533
Pebble 023
Taupe 016
Neutrail 020
Whisper 518
Wenge 531
Coffee Bean 04
Sunglow 506
Delft Pansy 035
Umber 078
Light Gray 025
Cobblestone 06
Barley 034
Elephant 519
Outer Space 525
Outer Banks 038
Limerick 507
Blue 013
Charcoal 03
Fjord 043
Meridian Bone 030
Baby’s Breath 018
Titanium 091
Blue Shadow 058
Chocolate 072
Asparagus 510
Midnight Blue 099
Graystone 092
Linen 011
Dune 032
Laurel Green 508
Nickel 090
Black Dahlia 01
Milk Chocolate 056
Balsam 511
Foxglove 526
Graphite 093
Gardenia 534
Driftwood 077
Bonsai 509
Gainsboro 523
Cricket 520
Bark 02
Clover 512
Cerulean 527
Medium Gray 014
True White 046
Dark Beige 037
Jojoba 513
Grullo 524
Storm Cloud 516
Heirloom Rose 502
Gulf Shores 517
Wisteria 528
Stone 024
Arctic White 029
Note: Since on-screen representations of our colors can vary, we suggest viewing physical samples in your space before placing an order. Request samples here.
Corner Blocks
Color-coordinated inside and outside corner blocks are available in standard heights of 4-3/4" and 8", plus custom heights in 1/2" increments.
Rubber Corner Blocks
Inside
Outside
166 Quarter Round Trim
1/2" × 1/2" Quarter Round Trim is the perfect finishing touch for many wall base installations and is available by request.
